310S ASTM A269 ท่อไร้รอยต่อสแตนเลสสำหรับแลกเปลี่ยนความร้อน
รายละเอียดสินค้า:
|
|
Place of Origin: | CHINA |
---|---|
ชื่อแบรนด์: | MTSCO |
ได้รับการรับรอง: | ISO 9001 & PED & AD2000 |
Model Number: | MTSCOSSST31 |
การชำระเงิน:
|
|
Minimum Order Quantity: | negotiable |
ราคา: | 4300-9800USD/TON |
Packaging Details: | Iron Case |
Delivery Time: | 30 Days |
Payment Terms: | T / T ; L / C |
Supply Ability: | 300 Tons / Month |
ข้อมูลรายละเอียด |
|||
Material: | Stainless Steel 300 Series | Standard: | EN 10216-5 ; ASTM A213 / SA213 ; ASTM A269 / SA269 Etc |
---|---|---|---|
Surface: | Annealing | NDT: | Eddy Current Or Hydraulic Test |
Type: | Seamless | Delivery Condition: | Soft / Hard |
แสงสูง: | Stainless Steel Seamless Tubing,ss Seamless Tubing |
รายละเอียดสินค้า
TP304L / 1.4306 Stainless Steel Seamless Tube With Bright Annealed Surface In Oil And Gas Industry
Item |
Description |
|
Basic Information |
Material Grade |
TP304 , TP304L , TP304H , TP316 , TP316L , TP316Ti , TP309S , TP310S , TP321 , TP321H , TP347 , TP347H , S31803 , S32750 , S32205 etc |
Outer Diameter |
3.18-101.6mm |
|
Wall Thickness |
0.5-20mm |
|
Length |
Normally fixed length 6m , can as per customer’s requirement |
|
Standard |
ASTM A213 ; ASTM A269 ; ASTM A312 ; ASTM A789 ; ASTM A790 ect . |
|
Process Method |
Cold Drawn or Cold Rolled |
Application
a) For fluid & gas transport
b) Structure & machining
c) Petrochemical
d) Environmental protection
e) Electricity
f) Instrument industry etc
Advantages
a) Superior surface finish
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Price Item: FOB , CFR , CIF or as negotiation
ASTM A213 / A213M Chemical Composition :
Elements | 304L(wt%) S30403 | 304(wt%) S30400 | 316L (wt%) S31603 | 316 (wt%) S31600 |
(C) Carbon, max | 0.035 | 0.08 | 0.035 | 0.08 |
(Mn) Manganese, max | 2 | 2 | 2 | 2 |
(P) Phosphorus, max | 0.045 | 0.045 | 0.045 | 0.045 |
(S) Sulfur, max | 0.03 | 0.03 | 0.03 | 0.03 |
(Si) Silicon, max | 1 | 1 | 1 | 1 |
(Ni) Nickel | 8.0 - 12.0 | 8.0 - 11.0 | 10.0 - 14.0 | 10.0 - 14.0 |
(Cr) Chromium | 18.0 - 20.0 | 18.0 - 20.0 | 16.0 - 18.0 | 16.0 - 18.0 |
(Mo) Molybdenum | N/A | N/A | 2.0 - 3.0 | 2.0 - 3.0 |
(Fe) Iron | Bal. | Bal. | Bal. | Bal. |
(Cu) Copper | N/A | N/A | N/A | N/A |
(N) Nitrogen | N/A | N/A | N/A | N/A |
Birmingham Wire Gauge BWG | |||||
Wall Thickness | Wall Thickness | ||||
BWG | IN | MM | BWG | IN | MM |
0 | 0.340 | 8.64 | 19 | 0.042 | 1.07 |
1 | 0.300 | 7.62 | 20 | 0.035 | 0.89 |
2 | 0.284 | 7.21 | 21 | 0.032 | 0.81 |
3 | 0.259 | 6.58 | 22 | 0.028 | 0.71 |
4 | 0.238 | 6.05 | 23 | 0.025 | 0.64 |
5 | 0.220 | 5.59 | 24 | 0.022 | 0.56 |
6 | 0.203 | 5.16 | 25 | 0.020 | 0.51 |
7 | 0.180 | 4.57 | 26 | 0.018 | 0.46 |
8 | 0.165 | 4.19 | 27 | 0.016 | 0.41 |
9 | 0.148 | 3.76 | 28 | 0.014 | 0.36 |
10 | 0.134 | 3.40 | 29 | 0.013 | 0.33 |
11 | 0.120 | 3.05 | 30 | 0.012 | 0.30 |
12 | 0.109 | 2.77 | 31 | 0.010 | 0.25 |
13 | 0.095 | 2.41 | 32 | 0.009 | 0.23 |
14 | 0.083 | 2.11 | 33 | 0.008 | 0.20 |
15 | 0.072 | 1.83 | 34 | 0.007 | 0.18 |
16 | 0.065 | 1.65 | 35 | 0.005 | 0.13 |
17 | 0.058 | 1.47 | 36 | 0.004 | 0.10 |
18 | 0.049 | 1.24 |
