บ้าน ผลิตภัณฑ์ท่อสแตนเลสสตีลไม่มีรอยต่อFluid Industrial Stainless Steel Big Size Seamless Pipe 1/8" - 48" S30908 / S31008
Fluid Industrial Stainless Steel Big Size Seamless Pipe 1/8" - 48" S30908 / S31008
Fluid Industrial Stainless Steel Big Size Seamless Pipe 1/8" - 48" S30908 / S31008 Fluid Industrial Stainless Steel Big Size Seamless Pipe 1/8" - 48" S30908 / S31008 Fluid Industrial Stainless Steel Big Size Seamless Pipe 1/8" - 48" S30908 / S31008
ติดต่อตอนนี้

Fluid Industrial Stainless Steel Big Size Seamless Pipe 1/8" - 48" S30908 / S31008

Minimum Order Quantity : negotiable ราคา : 2900-10000USD/TON
Packaging Details : Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA ชื่อแบรนด์: MTSCO
ได้รับการรับรอง: ISO 9001 & PED & AD2000 Model Number: MTSCOSSSP32

ข้อมูลรายละเอียด
Material: 300 Series Delivery Condition: Soft / Hard
NDT: Eddy Current Or Hydraulic Test End Cut: Plain End ( PE ) / Bevel End ( BE )
Type: Seamless Inspection: 100%
เน้น:

seamless stainless pipe

,

seamless stainless tube

รายละเอียดสินค้า

S30908 / S31008 Stainless Steel Big Size Seamless Pipe , 1/8" To 48" For Fuild And Gas Industry


Outer Diameter: 10.3mm-1219mm

Wall Thickness: 1.24mm-59.54mm

NPS: 1/8"-24"

Schedule: 5/5S,10/10S,20/20S,40/40S,80/80S,120/120S,160/160S

Material Grade: 304/304L/316/316L/321/309S/310S, etc

Standard: ASTM A269, ASTM A312, etc

Application: used in Fluid and Gas Transport, Structure and Machining,etc

Chemical Composition:



  C(max) Si(max) Mn(max) P(max) S(max) Cr Ni Mo Ti
TP309S/1.4833 0.080 1.00 2.00 0.045 0.030 22.0-24.0 12.0-15.0 0.75
TP310S/1.4845 0.080 1.00 2.00 0.045 0.030 24.0-26.0 19.0-22.0 0.75



Specifications :



NPS(Inch) D(mm) SCH5S SCH10S SCH40S STD SCH40 SCH80 XS SCH80S SCH160 XXS
1/8 10.30 - 1.24 1.73 1.73 1.73 2.41 2.41 2.41 - -
1/4 13.70 - 1.65 2.24 2.24 2.24 3.02 3.02 3.02 - -
3/8 17.10 - 1.65 2.31 2.31 2.31 3.20 3.20 3.20 - -
1/2 21.30 1.65 2.11 2.77 2.77 2.77 3.73 3.73 3.73 4.78 7.47
3/4 26.70 1.65 2.11 2.87 2.87 2.87 3.91 3.91 3.91 5.56 7.82
1 33.40 1.65 2.77 3.38 3.38 3.38 4.55 4.55 4.55 6.35 9.09
1 1/4 42.20 1.65 2.77 3.56 3.56 3.56 4.85 4.85 4.85 6.35 9.70
1 1/2 48.30 1.65 2.77 3.68 3.68 3.68 5.08 5.08 5.08 7.14 10.15
2 60.30 1.65 2.77 3.91 3.91 3.91 5.54 5.54 5.54 8.74 11.07
2 1/2 73.00 2.11 3.05 5.16 5.16 5.16 7.01 7.01 7.01 9.53 14.02
3 88.90 2.11 3.05 5.49 5.49 5.49 7.62 7.62 7.62 11.13 15.24
3 1/2 101.60 2.11 3.05 5.74 5.74 5.74 8.08 8.08 8.08 - -
4 114.30 2.11 3.05 6.02 6.02 6.02 8.56 8.56 8.56 13.49 17.12
5 141.30 2.77 3.40 6.55 6.55 6.55 9.53 9.53 9.53 15.88 19.05
6 168.30 2.77 3.40 7.11 7.11 7.11 10.97 10.97 10.97 18.26 21.95
8 219.10 2.77 3.76 8.18 8.18 8.18 12.70 12.70 12.70 23.01 22.23
10 273.10 3.40 4.19 9.27 9.27 9.27 15.09 12.70 12.70 28.58 25.40
12 323.9 3.96 4.57 - 6.35 8.38 9.53 10.31 14.27 17.48 12.7
14 355.6 3.96 4.78 6.35 7.92 9.53 9.53 11.13 15.09 19.05 12.7
16 406.4 4.19 4.78 6.35 7.92 9.53 9.53 12.7 16.66 21.44 12.7
18 457.2 4.19 4.78 6.35 7.92 11.13 9.53 14.27 19.05 23.83 12.7
20 508 4.78 5.54 6.35 9.53 12.7 9.53 15.09 20.62 26.19 12.7
22 559 4.78 5.54 6.35 9.53 12.7 9.53 - 22.23 28.58 12.7
24 610 5.54 6.35 6.35 9.53 14.27 9.53 17.48 24.61 30.96 12.7
26 660 - - 7.92 12.7 - 9.53 - - - 12.7
28 711 - - 7.92 12.7 15.88 9.53 - - - 12.7
30 762 6.35 7.92 7.92 12.7 15.88 9.53 - - - 12.7
32 813 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
34 864 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
36 914 - - 7.92 12.7 15.88 9.53 19.05 - - 12.7
38 965 - - - - - 9.53 - - - 12.7
40 1016 - - - - - 9.53 - - - 12.7
42 1067 - - - - - 9.53 - - - 12.7
44 1118 - - - - - 9.53 - - - 12.7
46 1168 - - - - - 9.53 - - - 12.7
48 1219 - - - - - 9.53 - - - 12.7





Fluid Industrial Stainless Steel Big Size Seamless Pipe 1/8" - 48" S30908 / S31008 0
